analog signal format system: PAL
angle of rotation: 360°
back light compensation (blc): Yes
bnc output ports: 1
built-in hdd: No
built-in light: Yes
built-in microphone: Yes
camera design: Eyeball
camera shutter speed: 1/25 - 1/100000 s
camera shutter type: Electronic
category code: HSC
certification: CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Part 15, Subpart B
cncode: 85258900
colour: White
connectivity technology: Wired
day/night mode: Yes
dc output voltage: 12
diameter: 9.71 cm
digital wide dynamic range (dwdr): Yes
digital wide dynamic range (dwdr) (panoramic camera): Yes
dimensions: φ97.1 mm × 93.8 mm
effective pixels: 2880 (H) × 1620 (V)
electronic shutter speed: PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s
environment: Outdoor
focal length: 3.6 - 4mm
form factor: Turret
frame rate: 30 fps
gain control type: Auto/Manual
height: 93.8 mm
highlight compensation (hlc): Yes
housing material: Plastic
international protection (ip) code: IP67
led type: IR/White
lens mount: M12
maximum aperture number: 1.6
maximum resolution: 2880 x 1620 pixels
microphone: Built-in
min. illumination: 0.005 Lux
minimum illumination: 0 lx
mirror: Yes
model: HDW1500CLQ-IL-A-0280B-S2
mounting type: Ceiling/Wall/Pole
net camera resolution: 5 - 7MP
network camera type: Outdoor
night vision: Yes
night vision distance: 20 m
noise reduction: Yes
noise reduction technology: 2D noise reduction
number of cameras: 1
number of illumination leds: 4
number of privacy masking areas: 8
operating relative humidity (h-h): 0 - 95%
operating temperature (t-t): -40 - 60 °C
package weight: 300 g
pan range: 0 - 360°
pixel resolution: 5 Mega Pixel
placement supported: Indoor & outdoor
power consumption: 4.5 Watts
power consumption (max): 4.5 W
power options: 12V
power source type: DC
power supply requirements: 12 VDC ± 30%
privacy masking: Yes
product colour: White
progressive scan: Yes
ptz control: No
sensor type: CMOS
shipping box depth: 12.5 cm
shipping box height: 11 cm
shipping box quantity: 1
shipping box weight: 0.31 kg
shipping box width: 12 cm
smart ir: Yes
storage relative humidity (h-h): 0 - 95%
storage temperature (t-t): -40 - 60 °C
supported graphics resolutions: 2560 x 1440
supported video modes: 1080p
tilt angle range: 0 - 78°
total megapixels: 5 MP
type: CCTV security camera
unit box height: 0.11
unit box length: 0.125
unit box width: 0.12
unit brutto volume: 0.00165 cubm
unit gross weight: 0.31 kg
unit net weight: 0.19 kg
video interface: HDCVI
warnings: Avoid direct contact with water to prevent electrical damage.
weight: 190 g
white balance: Area white balance
wide dynamic range (wdr): Yes
