12v power connector: Yes
antenna included: Yes
atx power connector (24-pin): Yes
audio chip: Realtek ALC1220
audio output channels: 7.1 channels
bios memory size: 256 Mbit
bios type: UEFI AMI
bluetooth: Yes
bluetooth version: 5.2
bundled software: Software
- ASRock Motherboard Utility (A-Tuning)
- ASRock Dragon 2.5G LAN Software
- ASRock Polychrome SYNC*
UEFI
- ASRock Full HD UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
cables included: SATA
certification: FCC, CE
chassis intrusion connector: Yes
clear cmos button: Yes
compatible processor series: AMD Ryzen™ 7000 Series
component for: PC
cpu fan connector: Yes
depth: 277 mm
ecc: Yes
ecc сompatibility: ECC
ethernet interface type: 5 Gigabit Ethernet
ethernet lan: Yes
ethernet lan (rj-45) ports: 2
front panel audio connector: Yes
headphone outputs: 1
lan controller: Dragon RTL8125BG
line-out: Yes
m.2 standoff included: Yes
maximum internal memory: 1 TB
memory channels: Quad-channel
memory slots type: DIMM
microphone in: Yes
motherboard chipset: AMD TRX50
motherboard chipset family: AMD
motherboard form factor: EATX
number of antenna connectors: 2
number of chassis fan connectors: 3
number of com connectors: 1
number of m.2 (m) slots: 2
number of memory slots: 4
number of microphone inputs: 1
number of sata connectors: 4
number of sata iii connectors: 4
number of storage drives supported: 6
number of usb 3.2 gen 2x2 (3.1 gen 2x2) type-c ports: 1
on-board graphics card: No
operating temperature (t-t): -40 - 70 °C
pci express x16 (gen 4.x) slots: 2
pci express x16 (gen 5.x) slots: 3
power source type: ATX
processor manufacturer: AMD
processor socket: Socket sTR5
product colour: Black
raid levels: 1
raid support: Yes
s/pdif out port: Yes
screws included: Yes
spdif optical output: Y
storage temperature (t-t): 10 - 35 °C
supported memory clock speed (max): 7600 MHz
supported memory module capacities: 16GB
supported memory types: DDR5-SDRAM
supported processor sockets: Socket sTR5
supported storage drive interfaces: Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)
thunderbolt headers: 1
top wi-fi standard: Wi-Fi 6E (802.11ax)
tpm connector: Yes
usb 2.0 connectors: 2
usb 3.2 gen 1 (3.1 gen 1) connectors: 1
usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity: 2
usb 3.2 gen 2 (3.1 gen 2) connectors: 1
usb 3.2 gen 2 (3.1 gen 2) type-a ports quantity: 4
usb 3.2 gen 2 (3.1 gen 2) type-c ports quantity: 1
usb 3.2 gen 2x2 type-c ports quantity: 1
wake-on-lan ready: Yes
wi-fi: Yes
wi-fi standards: 802.11b
width: 305 mm
wifi-ap antenna jack: 2
windows operating systems supported: Windows 11
